Starvisual Education Interactive Whiteboard Display
Transform lessons with the Starvisual Education Interactive Whiteboard Display—a 4K collaborative touchscreen designed for modern classrooms, training rooms and lecture spaces. Teachers and students can write, annotate, present and share content directly on the display for a more engaging learning experience.
- Display: 4K Ultra HD interactive LED panel
- Touch: Responsive infrared multi-touch with finger or stylus operation
- Writing: Digital whiteboard, annotation and screen-capture tools
- Platform: Integrated Android system with optional Windows OPS PC support
- Protection: Anti-glare toughened glass for everyday classroom use
- Audio: Built-in stereo speakers
- Connectivity: HDMI, USB, touch USB, LAN and wireless connectivity options
- Installation: Compatible with wall mounts and mobile display trolleys
- Applications: Schools, colleges, universities, academies and training centres
Available in a choice of screen sizes and configurations. Please select the required option or contact LCDTek for compatibility, installation and volume-order advice.
| Specification | 65″ | 75″ | 85″ | 98″ | 110″ |
|---|---|---|---|---|---|
| Panel | |||||
| Display Size (inch) | 65 | 75 | 85 | 98 | 110 |
| Backlight Type | E-LED | E-LED | E-LED | E-LED | E-LED |
| Resolution | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Active Display Area (mm) | 1425 × 803 | 1654 × 931 | 1874 × 1057 | 2160 × 121 | 2436.5 × 1370.5 |
| Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 |
| Brightness (cd/m²) | 300–350 | 300–350 | 300–350 | 300–350 | 300–350 |
| Contrast Ratio (Typ.) | 1200:1 / 5000:1 | 1200:1 / 5000:1 | 1200:1 / 5000:1 | 1200:1 / 5000:1 | 1200:1 / 5000:1 |
| Viewing Angle (H/V) | 178° / 178° | 178° / 178° | 178° / 178° | 178° / 178° | 178° / 178° |
| Color | 8bit 16.7M / 10bit 1.07B | 8bit 16.7M / 10bit 1.07B | 8bit 16.7M / 10bit 1.07B | 8bit 16.7M / 10bit 1.07B | 8bit 16.7M / 10bit 1.07B |
| Response Time (G-to-G) | 8ms | 8ms | 8ms | 8ms | 8ms |
| Operation Hour | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours |
| Touch Function | |||||
| Touch Type | 20-point IR touch | 20-point IR touch | 20-point IR touch | 20-point IR touch | 20-point IR touch |
| Writing Methods | Finger, stylus, or non-transparent objects ≥2mm (dual fine pens supported) | Same | Same | Same | Same |
| Touch Resolution | 32767 × 32767 | 32767 × 32767 | 32767 × 32767 | 32767 × 32767 | 32767 × 32767 |
| Touch Accuracy | ±1mm | ±1mm | ±1mm | ±1mm | ±1mm |
| Supported OS | Windows, Linux, Android | Same | Same | Same | Same |
| Touch Response Time | <8ms | <8ms | <8ms | <8ms | <8ms |
| Sound | |||||
| Audio Output | 20W, 8Ω (2 sets), Dual-channel stereo audio | Same | Same | Same | Same |
| Power | |||||
| Power Type | Internal | Internal | Internal | Internal | Internal |
| Power Supply | AC 100–240 V~, 50/60 Hz | Same | Same | Same | Same |
| Maximum Power Consumption | 260 W | 340 W | 400 W | 530 W | 880 W |
| Sleep Mode / Off Mode | ≤0.5 W | ≤0.5 W | ≤0.5 W | ≤0.5 W | ≤0.5 W |
| Mechanical Specs | |||||
| Protection Glass | Anti-glare | Anti-glare | Anti-glare | Anti-glare | Anti-glare |
| Mount Type | Wall mount bracket / Foot Stand | Same | Same | Same | Same |
| Environmental Conditions | |||||
| Operating Temperature | 0°C–40°C | Same | Same | Same | Same |
| Storage Temperature | -20°C–60°C | Same | Same | Same | Same |
| Operating Humidity | 10–90% RH | Same | Same | Same | Same |
| Storage Humidity | 10–90% RH | Same | Same | Same | Same |
| Android OS | |||||
| CPU | Amlogic T982, 1.9GHz, Quad-core ARM Cortex-A55 | Same | Same | Same | Same |
| RAM + Flash | 4G + 32G | Same | Same | Same | Same |
| LAN | 10M/100M Ethernet (Network version only) | Same | Same | Same | Same |
| Multimedia | Video: MPG, AVI, MP4, RM, RMVB, TS; Audio: MP3, WMA; Image: JPG, GIF, BMP, PNG | Same | Same | Same | Same |
| Wi-Fi | 802.11 b/g/n (Network version only) | Same | Same | Same | Same |
| Android Version | Android 13 | Same | Same | Same | Same |
| I/O Ports | RJ45 ×1, TOUCH USB ×1, USB3.0 ×1, USB2.0 ×1, RS232 ×1, HDMI IN ×1, AV IN ×1, Earphone ×1, COAX ×1, Type-C ×1 | Same | Same | Same | Same |
| OPS Module (Optional Windows PC) | |||||
| Processor | Intel® i5 6th Gen (6400 / 6400T / 6500 / 6500T) | Same | Same | Same | Same |
| RAM + Storage | 8G + 256G SSD | Same | Same | Same | Same |
| I/O | DC 12V ×1, RJ45 ×1, VGA ×1 (output), USB ×4, HDMI ×1 (output), Audio ×1 (output), Microphone (input) | Same | Same | Same | Same |
| Connection | Ethernet (RJ45), Wi-Fi, Bluetooth (optional) | Same | Same | Same | Same |
| Operating System | Windows 10/11 | Same | Same | Same | Same |
| Certification | CE, ROHS, FCC | Same | Same | Same | Same |
| Accessories Included | Wall mount bracket, Presentation software, Remote control, Key, Power cable | Same | Same | Same | Same |
| Quality Assurance | 1 year | Same | Same | Same | Same |
| Packaging | Carton box or honeycomb box + wooden case | Same | Same | Same | Same |
