Starvisual Square TFT Digital Signage Display
Make your content stand out with the Starvisual Square TFT Digital Signage Display. Its distinctive 1:1 screen format is ideal for retail promotions, digital menus, product showcases, wayfinding, galleries and other commercial signage applications. The slim, professional enclosure can be integrated into modern interiors or installed as a dedicated digital display.
- Brand: Starvisual Display
- Display technology: Commercial TFT LCD
- Screen format: Square 1:1 aspect ratio
- Orientation: Landscape or portrait-equivalent square installation
- Content: Images, video and digital advertising
- Installation: Wall-mounted or integrated installation, subject to model
- Connectivity: HDMI, USB and network-enabled options available
- Media player: Android and external-player configurations available
- Applications: Retail, hospitality, exhibitions, museums, corporate and public spaces
Screen size, resolution, brightness, connectivity and enclosure options vary by configuration. Please contact LCDTek for current specifications and availability.
| Specification | 17″ | 22″ | 26.5″ | 33.2″ | 44.9″ |
|---|---|---|---|---|---|
| Panel | |||||
| Display Size (inch) | 17 | 22 | 26.5 | 33.2 | 44.9 |
| Resolution | 1920 × 1920 | 1920 × 1920 | 1920 × 1920 | 1920 × 1920 | 1280 × 1280 |
| Active Display Area (mm) | 305.28 × 305.28 | 394.56 × 394.56 | 475.776 × 475.776 | 596.16 × 596.16 | 806.42 × 806.42 |
| Aspect Ratio | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 |
| Brightness (cd/m²) | 500 | 500 | 500 | 500 | 700 |
| Contrast Ratio (Typ.) | 1000:1 | 1000:1 | 1000:1 | 1000:1 | 4000:1 |
| Viewing Angle (H/V) | 178° / 178° | 178° / 178° | 178° / 178° | 178° / 178° | 178° / 178° |
| Color Depth | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
| Response Time (G-to-G) | 6.5 ms | 6.5 ms | 6.5 ms | 6.5 ms | 6.5 ms |
| Operation Hours | 24/7 | 24/7 | 24/7 | 24/7 | 24/7 |
| Sound | 5W, 8Ω (2 sets), Dual-channel stereo audio output | Same | Same | Same | Same |
| Power | |||||
| Power Type | Internal | Internal | Internal | Internal | Internal |
| Power Supply | AC 100–240 V~, 50/60 Hz | Same | Same | Same | Same |
| Maximum Power Consumption (W/h) | 20 | 20 | 25 | 30 | 50 |
| Sleep Mode | <0.5 W | <0.5 W | <0.5 W | <0.5 W | <0.5 W |
| Off Mode | <0.5 W | <0.5 W | <0.5 W | <0.5 W | <0.5 W |
| Mechanical Specifications | |||||
| Protection Glass | N/A | N/A | N/A | N/A | N/A |
| Stand Type | Wall mount | Wall mount | Wall mount | Wall mount | Wall mount |
| Environmental Conditions | |||||
| Operating Temperature | 0°C–50°C | Same | Same | Same | Same |
| Storage Temperature | -10°C–55°C | Same | Same | Same | Same |
| Operating Humidity | 10–80% | Same | Same | Same | Same |
| Storage Humidity | 5–95% | Same | Same | Same | Same |
| OS / Media Player | |||||
| Processor | RK3568, 1.8GHz, Octa-core | Same | Same | Same | Same |
| RAM | 2 GB DDR3 | Same | Same | Same | Same |
| Built-in Memory | 8 GB FLASH | Same | Same | Same | Same |
| USB Ports | 2 × USB 2.0 HOST | Same | Same | Same | Same |
| LAN | 10M/100M Ethernet (Network version only) | Same | Same | Same | Same |
| External Memory | 8 GB SD card (up to 32 GB) | Same | Same | Same | Same |
| Multimedia Formats | Video: MPG, AVI, MP4, RM, RMVB, TS; Audio: MP3, WMA; Image: JPG, GIF, BMP, PNG | Same | Same | Same | Same |
| Media Resolution Support | 1080P, 1080I, 720P, 480P & multiple resolutions | Same | Same | Same | Same |
| Wi-Fi | 802.11 b/g/n (Network version only) | Same | Same | Same | Same |
| Operating System | Android 9.0 | Same | Same | Same | Same |
| Certification | CE, RoHS | Same | Same | Same | Same |
| Accessories Included | Scheduling software, Remote control, Key, Power cable, SD card | Same | Same | Same | Same |
| Quality Assurance | 1 Year | Same | Same | Same | Same |
| Packaging | Carton box / honeycomb box + wooden case | Same | Same | Same | Same |
SD510-SM-DS
