CD Tech 2.9 Inch Bar Style Display, 300cd/m²
Compact 2.9-inch bar-style LCD display from CD Tech, designed for space-constrained user interfaces and information panels. Its elongated format and 300 cd/m² brightness provide clear, readable content for industrial controls, handheld equipment, appliances and embedded applications.
- Manufacturer: CD Tech
- Display size: 2.9 inches
- Display format: Bar style / ultra-wide
- Brightness: 300 cd/m²
- Product type: LCD display module
- Typical applications: Control panels, instrumentation, status displays and embedded systems
Please check the product datasheet for resolution, interface, dimensions, operating temperature and electrical requirements before ordering.
S029HQ05NS
Data sheet
- Resolution
- 320 (RGB) x 120 Resolution
- Active Area (W x H mm)
- 70.08 x 26.28
- Overall Dia. (W x H x D mm)
- 76.90 x 38.22 x 3.26
- Backlight Brightness
- 300 cd/m2
- Backlight Lifetime
- 20K Hours
- Backlight Types
- LED
- Backlight Colours
- White
- Interface Mode
- RGB
- Diagonal
- 2.90 inch
- LCD Type
- IPS
- Viewing Direction
- ALL
- Operating Temperature
- -20 to 70 deg. C
- Storage Temperature
- -30 to +80 deg. C
- Polarizer Modes
- Transmissive
