Acrowise 4.6 Inch Bar Style TFT Display
Acrowise 4.6" Bar Style TFT Display is a compact, ultra-wide LCD module designed for applications where space is limited or a conventional display format is unsuitable. Its stretched bar layout is ideal for control panels, smart appliances, instrumentation, status displays and embedded HMI systems.
- Manufacturer: Acrowise
- Display size: 4.6-inch diagonal
- Display technology: TFT LCD
- Format: Ultra-wide bar / stretched display
- Typical applications: Industrial controls, instrumentation, smart appliances, information panels and embedded systems
- Integration: Suitable for OEM and custom display projects
Please refer to the product datasheet or contact LCDTek to confirm resolution, interface, brightness, viewing angle, touch-panel options and mechanical dimensions for the required Acrowise part number.
Download Specification
AWL-320960T46N01
Data sheet
- Resolution
- 320(H) X 960 (V)
- Active Area (W x H mm)
- 36.77 x 110.30
- Overall Dia. (W x H x D mm)
- 41.57 x 118.80 x 2.50
- Backlight Brightness
- 300 cd/m2
- Backlight Lifetime
- 25K hrs.
- Backlight Types
- LED
- Backlight Colours
- White
- Interface Mode
- RGB
- Viewing Direction
- Super Wide View
- Operating Temperature
- -20 to 70 deg. C
- Storage Temperature
- -30 to +80 deg. C
