EDT 7.0 Inch TFT LCD Display, CTP, Ext Temp
High-brightness 7.0 inch EDT display with an integrated capacitive touch panel (CTP). Delivering up to 1000 cd/m² brightness and an extended operating temperature range, it is well suited to industrial, outdoor-facing and high-ambient-light applications.
- Manufacturer: EDT
- Display size: 7.0 inches
- Brightness: 1000 cd/m²
- Touch technology: Capacitive touch panel (CTP)
- Temperature rating: Extended operating temperature
- Application: Industrial and high-brightness display systems
Please refer to the product datasheet for the exact resolution, interface, dimensions and operating temperature limits.
Multi Inno 6.2 inch display, bar style display, stretched LCD screen, 6.2 inch LCD screen, bar type LCD, digital signage display, compact LCD display, stretched display UK
EIMLO70022DYA
Data sheet
- Resolution
- 1200 * 1920
- Active Area (W x H mm)
- 94.5W * 151.2H mm
- Overall Dia. (W x H x D mm)
- 106.5W * 163.2H * 5.25D mm
- Backlight Brightness
- 850 cd/m2
- Backlight Lifetime
- 50K Hours
- Backlight Types
- LED
- Backlight Colours
- White
- Interface Mode
- MIPI
- Diagonal
- 7.00 inch
- LCD Type
- IPS
- Viewing Direction
- Super Wide View
- Operating Temperature
- -30 to +80 deg. C
- Storage Temperature
- -30 to +80 deg. C
- Polarizer Modes
- Transmissive
- CTP Controller IC
- Ilitek ILI2130
- Display Controller/Driver IC
- FOCAL FT8206
