120 x 24 Graphic Module

Data sheet

Resolution

120 x 24 Dots

Active Area (W x H mm)

60.50 x 17.70

Overall Dia. (W x H x D mm)

84.00 x 44.00

Backlight Types

(L)

Interface Mode

4 Bit

Operating Temperature

-20 to 70 deg. C

Storage Temperature

-30 to +80 deg. C

Character Size (mm)

0.47 x 0.58

Assembly Type

COB

Duty Cycle

1/24

Display Controller/Driver IC

ET7010
