128 x128 Graphic Module

Data sheet

Resolution

128 x 128 Dots

Active Area (W x H mm)

69.00 x 69.00

Overall Dia. (W x H x D mm)

75.40 x 83.40

Backlight Types

(L)

Interface Mode

8 Bit/Serial/I2C

Operating Temperature

-20 to 70 deg. C

Storage Temperature

-30 to +80 deg. C

Character Size (mm)

0.47 x 0.47

Assembly Type

COG

Duty Cycle

1/128

Connector

FPC

Display Controller/Driver IC

UC1617W
