Display Format : 480 (RGB) x 234
Contrast Ratio : 4 : 3
Screen Size : 2.4 inch
Overall Dia.(W x H x D mm) : 55.50 x 47.90 x 3.17
|
Active Area (W x H mm) : 48.00 x 35.69
Driver Board Size W x H x D) : 50.00 x 50.00 x 5.20
|
|
Backlight Brightness : 300 cd/m2
Viewing Angle : 50/65/65/65
|
| Working Voltage : 9 - 15V |
Working Current : DC 50mA +/- 10mA
|
| Power Consumption : 0.6W Typ. |
| Operating Temperature : -10 to +60 deg. C |
| Storage Temperature : -20 to +70 deg.C |
Part Number: LTKJD24TWD-T24P138
JD24TWD-T24P138
