144 x 12 Graphic Module

Data sheet

Resolution

144 x 12 Dots

Active Area (W x H mm)

92.00 x 11.80

Overall Dia. (W x H x D mm)

100.00 x 30.00

Backlight Types

(L/M/E)

Interface Mode

4 Bit

Operating Temperature

-20 to 70 deg. C

Storage Temperature

-30 to +80 deg. C

Character Size (mm)

0.63 x 0.82

Assembly Type

COB

Duty Cycle

1/24

Display Controller/Driver IC

ET7010
