10.1" IPS Sunlight Readable TFT Display, 1000cd/m2, LVDS Interface with 25K Lifetime Hours

Data sheet

Resolution

1280 (RGB) x 800 Resolution

Active Area (W x H mm)

216.96 x 135.60

Overall Dia. (W x H x D mm)

229.06 x 148.70 x 2.51

Backlight Brightness

1000 cd/m2

Backlight Lifetime

25K hrs.

Backlight Types

LED

Backlight Colours

White

Interface Mode

LVDS

Diagonal

10.1 inch

LCD Type

IPS

Viewing Direction

ALL

Operating Temperature

-20 to 70 deg. C

Storage Temperature

-30 to +80 deg. C

Polarizer Modes

Transmissive
